Hydraulic Cone Crusher

【Introduction】:

Type:Secondary Crushing.
Input Size:95mm--353mm.
Processed Materials:Limestone, Granite, Gabbro, Basalt, River Stone, Coal Gangue, Quartz, Diabase,Iron Ore, Copper Ore, Zinc Ore, Manganese Ore, etc. (for Hard Stone).
Applications:Aggregates Shaping, Mechanism sand, Bituminous Concrete, Metal Mine, Chemical, Road, Railway,Metallurgy, Construction, Highway, Water Conservancy.
Capacity:90-1200 TPH.

Chat Online Leave Message

share to

Description

Hydraulic cone crushers are widely applied in metallurgical, construction, road building, chemical and phosphatic industry. It is suitable for hard and mid-hard rocks and ores, such as iron ores, copper ores, limestone, quartz, granite, grit stone, etc.

Hydraulic cone crusher not only improves the production capacity and crushing efficiency, but also widens applying area, hardness range of materials from limestone to basalt. It has a great crushing performance in the work of medium-size crushing, fine crushing and super fine crushing. The crusher is the improved type of spring cone crusher and can be used to replace ordinary hydraulic cone crusher in the field of mining and construction. It is the most ideal equipment for large stone crushing factory and mining industry.

Hydraulic Cone Crusher

Features

1. High crushing ratio and production efficiency.
2. It is easy in operation, reliable in performance and adjustable in the size of the end products;
3. Good particle shape of final product.
4. Thin oil lubrication makes the life time increased.
5.Easy operation and easy to maintain;
6. Easy maintenance and operation.
7. Easy to clear the cavity,downtime will be reduced.

Hydraulic Cone Crusher

Working principle

When the hydraulic crusher cone is working, the engine rotates around a fixed point driven by the belt wheel or the coupling. The transmission shaft and the conical part of the cone crusher swing under the force from the eccentric bushing, which makes the crushing wall close to the pierced mortar wall at intervals. Then, the ores will be impacted, squeezed and bent constantly in the crushing chamber.

At last, the whole ore crushing process is finished. The perfect combination of high-performance crushing chamber and high crushing frequency improves the handling ability of the Hydraulic crusher cone to a greater degree.Stable aggregate are produced finally. The eligible raw material falls down from the gap of the broken wall. The others will be kept crushing until it reaches the desired size.

Hydraulic Cone Crusher

Specifications

Model
Cavity
Standard Type
Short Type
Power
Capacity (t/h)
Feeding Size (mm)
Min Discharging Size (mm)
Feeding Size (mm)
Min Discharging Size (mm)
(kw)
XHP200
Super coarse




132-200
90-250
Coarse
185
19
76
10
Medium
125
17
54
6
Fine
95
13
23
6
Super Fine


10
5
XHP300
Super coarse
230
25


180-250
115-440
Coarse
210
20
75
10
Medium
150
15
50
8
Fine
105
10
20
6
Super Fine


20
6
XHP400
Super coarse
295
30


280-355
140-630
Coarse
250
25
90
10
Medium
195
20
50
8
Fine
110
14
40
6
Super Fine


30
6
XHP500
Super coarse
330
30


355-450
175-790
Coarse
285
25
90
13
Medium
200
20
55
10
Fine
133
16
40
8
Super Fine


35
6
XHP800
Super coarse
353
32


550-630
260-1200
Coarse
297
32
155
13
Medium
267
25
92
10
Fine
219
16
33
6
Super Fine
